VISCO JET® VJ455

The ideal solution for flexible and convenient stirring of transport containers

Extremely flexible even for the most demanding requirements

The VISCO JET® VJ455 stand agitator with electric height adjustment is the optimal solution for mixing different transport containers such as 1,000 litre IBCs, 200-l plastic drums, hobbocks or customised stainless steel tubs. Different drive variants, lifting heights and mixing element solutions also enable an efficient and effective solution for the stirring task.

The high-quality stainless steel design as well as the internal lifting mechanism and integrated cable guide facilitate quick and easy cleaning of the agitator and safe operation.

In combination with our control solutions, it is also possible to control stirring speed, stirring time, stirring level and even recipe setting and selection.

VJ455 highlights

g

Efficient

Compact and efficient solution for container heights of up to 1,200 mm or 1,400 mm

Self-explanatory

Intuitive and safe to operate

d

Fits

Individually configurable

The multi-function tool
for increased productivity

ATEX

ATEX version of the agitator for zones 0 or 21 possible

Flexible

1,200 mm or 1,400 mm lifting height allow maximum flexibility when stirring different container sizes

Strong

Various drive powers from 1.5 – 3 kW for a customised and sustainable solution to the customer’s stirring task

Comfortable

The lift height can be quickly and easily adjusted electrically at the touch of a button on the switch set or control panel of the control unit. The control unit is mounted directly on the agitator thus ensuring an ergonomic user-friendly process

Safe

High level of safety during agitator operation thanks to the integrated working position switch and limit switch, plus container detection on the stand base. Operation of the agitator is only enabled after positive feedback from the safety switches.

Compatible

Can be combined with all VISCO JET® mixing element unit solutions for optimum stirring results with consistent product quality over the long term

e

Standard connection

The agitator is equipped with a high-voltage connection and is therefore ready for immediate use in the stirring process.

c

Well shielded

Internal cable routing for safe and injury-free handling

Variable

Built-on frequency converter for individual speed control

a

Perfect finishing

High-quality stainless steel stand and the roller belt cover in hard-wearing PUR for quick and easy cleaning to avoid long downtimes during the production process.

Perfect fit

The agitator can be mounted on the floor using a base or on the wall with a mounting plate. If the room conditions change, the agitator can be flexibly converted to the respective other installation type and is thus immediately ready for use again.

Well thought-out, right down to the smallest detail

The VJ455 with electric lift height adjustment is extremely convenient to handle and enables an automated manufacturing process through various control solutions.

  • Drive power: 1.5 – 3.0 kW
  • Speed adjustment by means of a built-in frequency converter
  • Power supply: 400 V / 50 Hz incl. plug for plug and play solution
  • Lift height adjustment: Electric
  • Lift height: 1,200 mm/1,400 mm

Lift height: 1,200 mm:

  • Lift fully extended: 2,099 mm
  • Retracted: 1,699 mm
  • Additional height of the stand base for floor mounting: 450 mm or 900 mm

Lift height: 1,400 mm:

  • Lift fully extended: 2,299 mm
  • Retracted: 1,699 mm
  • Additional height of the stand base for floor mounting: 450 mm or 900 mm
  • Can be mounted directly on a wall using a mounting plate
  • Can be mounted directly on the floor by means of a base
  • Working position switch
  • Limit switch
  • Container identification

Operation of the agitator is only enabled after positive feedback from the safety switches.

  • Stand: Stainless steel 1.4404
  • Roller belt cover: hard-wearing PUR
  • Agitator unit: Stainless steel 1.4404/1.4571
  • Can be combined with all VISCO JET® mixing elements
  • 2006/42/EU: Machine safety
  • 2014/30/EU: Electromagnetic compatibility
  • 2014/35/EU: Electrical equipment designed for use within certain voltage limits
  • Optional: ATEX version according to RL2014/34/EU
  • Quick-release coupling for easy and uncomplicated changing of the agitator units for different containers and stirring tasks without long set-up times.
  • Ultrasonic sensor for level-dependent speed control
  • ATEX design of the agitator for zones 0 or 1 in the container according to the requirements of Directive 2014/34/EU
  • Individual or standardised lid design as splash protection or for zone separation in ATEX applications
  • Ratchet belt solution or container clamping for light or smaller containers with very viscous media to mechanically prevent the container from twisting or moving and thus minimise the risk of accidents
  • Positioning aid for quick positioning of an IBC in front of the agitator
  • Flexibly adjustable container detection and fixation for use with widely varying container diameters to ensure maximum safety for the user
  • Ground or electropolished finish of all components in contact with the product with ra[simbolo minore]0.8 µm or ra[simbolo minore]0.4 µm for even easier, faster and safer cleaning
  • Stainless steel version of the roller belt cover possible
  • Different control variants with safety category SIL3, which make the manufacturing process more efficient and reproducible, e.g. by setting the stirring speed and stirring time
  • Mounting kit for easy, quick and safe mounting of the agitator on the floor or wall

At home in your industry

l

Ceramics

m

Cosmetics and soap

n

Sweets

o

Food and beverages

p

Paper

q

Milk products

r

Colors and paints

s

Chemistry

u

Pharmaceuticals

v

Mining

w

Petrochemistry

Container and plant engineering
